Ortofon 2M Blue Cartridge
Ortofon 2M Blue Cartridge
Ortofon 2M Blue Cartridge

Ortofon 2M Blue Cartridge

Regular price $335.00
/
Tax included.

The 2M Blue adds more dynamics and resolution, sounds more open and reproduces more details compared to the 2M Red model.

  • An improved engine, which provides an increased output of 5.5 mV and an optimized sound reproduction and a high level of sonic accuracy.
  • Nude Elliptical diamond and split pole pins with a copper wire.
  • The cartridge body is manufactured from Hopelex, an environment-friendly material which ensures high rigidity while eliminating unwanted resonances.

The 2M Blue adds more dynamics and resolution, sounds more open and reproduces more details compared to the 2M Red.

2M Blue accessories included the package:

  •     1 x Stylus brush
  •     1 x Screwdriver
  •     2 x Screw M2,5 x 5
  •     2 x Screw M2,5 x 7

Specifications

  • Output voltage at 1000 Hz, 5cm/sec.  -   5.5 mV
  • Channel balance at 1 kHz  -   1.5 dB
  • Channel separation at 1 kHz  -  25 dB
  • Channel separation at 15 kHz  - 15 dB
  • Frequency range at - 3dB  -  20-25.000 Hz
  • Frequency response  -  20-20.000 Hz + 2 / - 1 dB
  • Tracking ability at 315Hz at recommended tracking force  -  80 µm
  • Compliance, dynamic, lateral  -  20 µm/mN
  • Stylus type  -  Nude Elliptical
  • Stylus tip radius  -  r/R 8/18 µm
  • Tracking force range  -  1.6-2.0 g (16-20 mN)
  • Tracking force, recommended  -  1.8 g (18 mN)
  • Tracking angle  -  20°
  • Internal impedance, DC resistance  -  1.3 kOhm
  • Internal inductance  -  700 mH
  • Recommended load resistance  - 47 kOhm
  • Recommended load capacitance  -  150-300 pF
  • Cartridge colour, body/stylus  -  Black/Blue
  • Cartridge weight  -  7.2 g
